DLA-N5B
×
D-ILA Projector
DLA-N5B Archived
JVC DLA-N5 D-ILA projector is wrapped in a whole new design, which is packed with the latest projection features. For instance with the new 0.69-inch native 4K D-ILA device, the projector can produce high-definition native 4K resolution (4096 x 2160) images from its all-glass 65 mm diameter lens system. HDR10 content can be projected at optimum quality with Auto Tone Mapping function, and the new Frame Adapt HDR function, which analyses HDR10 content frame-by-frame and automatically performs frame adjustment for optimal image projection. Combining brightness of 1,800 lm, dynamic contrast ratio of 400,000:1, and 18-bit equivalent gamma accuracy for smooth gradation, the projector reproduces life-like images close to reality as we perceive with our eyes. Renewed Clear Motion Drive together with Motion Enhance, which optimizes the D-ILA driving device according to image movement, significantly reduce blur compared to other projectors.
“The New D-ILA Projector Microsite”
- Complies with the latest HDMI/HDCP 2.2 standard to enable full spec 4K signal input with 18Gbps transmission band-width (4K60P 4:4:4, 4K60P 4:2:2/36-bit, 4K24P 4:4:4/36-bit)
- Light source: NSH 265 W lamp
- Resolution: 4096 x 2160
- Input connectors: HDMI x 2 (3D, Deep Colour/HDCP 2.2)
- Output and control connectors: RS-232C (D-sub 9pin) x 1, LAN (RJ-45) x 1, Trigger x 1 (Mini jack), 3D Sync x 1 (Mini-DIN 3pin)
- 3D formats: Frame Packing, Side-by-Side (Half), and Top & Bottom
- New 0.69 inch 4K D-ILA (4096 x 2160) device x 3
- High-definition display at 4K resolution (4096 x 2160)
- 17-element, 15-group all-glass 65mm diameter high-quality lens
- Multiple Pixel Control image processor accurately reproduces images closer to the original
- Exceptionally bright 1,800 lm means bright, high-resolution images
- Deep Blacks are realized by a High Native Contrast Ratio of 40,000:1 (Dynamic Contrast Ratio 400,000:1)
- Frame Adapt HDR dynamically tone maps any HDR10 content frame-by-frame and automatically performs adjustment to achieve optimal images close to reality as seen by human eyes
- As a part the Frame Adapt HDR, the projector offers improved gamma processing accuracy from 12- to 18-bit equivalent to reproduce smoother and finer gradation
- Auto Tone Mapping function automatically adjusts settings for optimum HDR10 image quality
- For easy reproduction, the projector switches automatically to HDR picture mode when HDR10 signals are received
- Display the MaxCLL and MaxFALL mastering data available for HDR content on some UHD Blu-ray discs
- Compatible with Hybrid Log-Gamma that is expected to be used widely in future broadcasting
- Installation Mode centrally manage nine settings related to installation to enjoy video best suited for each environment
- Nine settings of Installation Mode include Lens Control, Pixel Adjustment, Mask, Anamorphic on or off, Screen Adjust, Installation Style, Keystone, Pincushion, and Aspect; stored installation modes for various environments can be called up
- Renewed Clear Motion Drive supporting 4K60P (4:4:4) signal improves moving images more than ever
- Motion Enhance technology reduces residual images and blurring that are often found in fast-moving images by optimally controlling the drive of D-ILA devices
- Low Latency Mode suppresses display delay for faster response when receiving signals from PC and game consoles
- Colour Management System with 6-axis Matrix
- Auto-Calibration Function using an optical sensor* is capable of optimizing essential elements in the image, including colour balance, gamma characteristics, colour space and colour tracking
Technical Specifications
Manuals
Technical Specifications
- Device
- 0.69-inch Native 4K DILA Device (4096x2160) x3
- Resolution
- 4096 x 2160
- Lens shift function
- +/-80% vertical & +/-34% horizontal, motorised in 16:9 aspect mode
- Light source lamp
- NSH 265 W
- Lens
- All-glass lens with 65 mm diameter
- Zoom
- 2X zoom & focus, motorised
- Lamp life
- Approx. 4500 hours in Low mode
- Brightness
- 1,800 lm
- Contrast Ratio
- Native: 40,000:1, Dynamic: 400,000:1
- Video input signals
- Digital: 480p, 576p, 720p 60/50, 1080i 60/50, 1080p 60/50/24, 3840 x 2160p 60/50/30/25/24, 4096 x 2160p 60/50/30/25/24
- HDMI
- VGA/ SVGA/ XGA/ WXGA/ WXGA+/ SXGA/ WSXGA+
- HDMI
- 2 (3D/Deep Colour/HDCP 2.2)
- 3D sync
- 1 (Mini DIN 3-pin)
- Trigger
- 1 (mini jack, DC12V/100mA)
- RS232C
- 1 (D-sub 9-pin)
- LAN (RJ45)
- 1 (RJ-45)
- Service
- 1 (USB Type A) (for firmware update)
3D
- Side-by-side
- 720p 60/50, 1080p 60/50/24, 1080i 60/50
- Frame packing
- 720p 60/50, 1080p 24
- Top & bottom
- 720p 60/50, 1080p/24
General
- Power requirement
- AC100V-240V, 50/60Hz
- Projector in use
- 400 W
- Dimensions: W x H x D, mm
- 500 x 234 x 495
- Weight, kg
- 19.6
- Stand-by
- Normal: 1.5W, Eco-mode: 0.3W
Manuals
| Instruction manual (-Software Ver.3.10) | Dutch | 2018 | 8.28MB | View | Download |
| Instruction manual (Software Ver.3.50-) | Dutch | 2018 | 8.30MB | View | Download |
| Instruction manual (Software Ver.3.50-) | English | 2018 | 8.02MB | View | Download |
| Instruction manual (-Software Ver.3.10) | English | 2018 | 8.28MB | View | Download |
| Instruction manual | French | 2018 | 8.29MB | View | Download |
| Instruction manual (Software Ver.3.50-) | French | 2018 | 8.32MB | View | Download |
| Instruction manual (Software Ver.3.50-) | German | 2018 | 8.31MB | View | Download |
| Instruction manual (-Software Ver.3.10) | German | 2018 | 8.29MB | View | Download |
| Instruction manual (Software Ver.3.50-) | Italian | 2018 | 8.31MB | View | Download |
| Instruction manual (-Software Ver.3.10) | Italian | 2018 | 8.29MB | View | Download |
| Instruction manual (Software Ver.3.50-) | Russian | 2018 | 8.53MB | View | Download |
| Instruction manual (-Software Ver.3.10) | Russian | 2018 | 8.39MB | View | Download |
| Instruction manual (Software Ver.3.50-) | Spanish | 2018 | 8.31MB | View | Download |
| Instruction manual (-Software Ver.3.10) | Spanish | 2018 | 8.30MB | View | Download |
| Instruction manual (Software Ver.3.50-) | Traditional Chinese | 2018 | 8.43MB | View | Download |
| Instruction manual (-Software Ver.3.10) | Traditional Chinese | 2018 | 8.39MB | View | Download |
