LX-UH1B
×
DLP Projector
LX-UH1B Archived
CAD 2,499.99
The LX-UH1 is a high-performance 4K UHD/HDR home theater projector with compact design and wide lens shift for easy installation; also thanks to its 2,000-lumen output there is no need to always pull the curtain. This projector is ideal for all your broadcast, streaming and BD viewing.
- HDR (high dynamic range) for more realistic, dynamic images
- 1.6x high-resolution lens
- Wide lens shift function: +/-60% vertical, +/-23% horizontal
- HDCP2.2 compatibility with HDMI 1 terminal to support video-streaming services and copyright-protected content including UHD BD discs
- Connectors: PC in, HDMI 1 with HDCP2.2 support, HDMI 2, USB Mini B, Trigger (12 V), USB Mini A (1.5 A power supply), and RS-232
- Compatible with HDMI standards (4K/60P 4:4:4) and HDCP 2.2
- 4K resolution (3840 x 2160) achieved
- 4K input specs: Supports 4K/60p, 4:4:4/36bit, 4K/60p 4:2:2/36bit, and 4K/24p 4:4:4/36bit signals - for more vivid colors and subtle gradations
- Compact design for installation convenience: just 33 cm by 33 cm, and less than 13.5 cm high
- 0.47-inch DMD for bright high-definition 4k images
- 100% coverage of Rec. 709 gamut
- Brightness: 2,000 lm
- Dynamic contrast ratio: 100,000:1
Technical Specifications
Manuals
Technical Specifications
- Device
- 0.47" DMD (1920 x 1080)
- Resolution
- 3840 x 2160
- Lens shift function
- +/-60% vertical & +/-23% horizontal, motorized
- Light source lamp
- NSH 240 W
- Zoom
- 1.6x manual zoom/focus lens
- f
- 14.3 - 22.9 mm
- F
- 1.809
- Projection size
- 60" to 200"
- Lamp life
- Approx. 4,000 hours in normal mode, 10,000 hours in eco mode
- Brightness
- 2,000 lm
- Contrast Ratio
- Dynamic: 100,000:1
- HDMI
- 2 (HDCP2.2 x 1, HDCP1.4 x1)
- PC
- 1 (D-sub 15pin)
- USB
- 1 (Type A; Power supply 5 V/1.5 A)
- Trigger
- 1 (mini jack, DC12V/0.1 A)
- RS232C
- 1 (D-sub 9-pin)
- USB
- 1 (Type B mini for service)
General
- Noise level
- 29 dB (Eco)/ 33 dB (Normal)
- Power requirement
- AC110 V-240 V, 50/60 Hz
- Projector in use
- 370 W
- Dimensions: W x H x D, mm
- 333 x 135 x 331.5 mm
- Dimensions: W x H x D, inches
- 13-1/8 x 5-5/16 x 13-1/16
- Weight, kg
- 4.8
- Weight, lbs
- 10.56
- Stand-by
- 0.5 W
Manuals
| Instruction manual | Dutch | 2018 | 4.33MB | View | Download |
| Instruction manual | English | 2018 | 4.35MB | View | Download |
| Instruction manual | French | 2018 | 4.31MB | View | Download |
| Instruction manual | German | 2018 | 4.34MB | View | Download |
| Instruction manual | Italian | 2018 | 4.33MB | View | Download |
| Instruction manual | Russian | 2018 | 4.18MB | View | Download |
| Instruction manual | Spanish | 2018 | 4.29MB | View | Download |
