You can assign different settings to each of the five Scene File buttons and save them accordingly. This is useful at job sites where speed is required, as you can recall the settings according to the shooting conditions by pressing the relevant button.
RM-LP25
×
Remote Controller for JVC ENG/Studio Camcorders
RM-LP25
This console remote unit provides key operation of the camera when connected in a fiber or multicore set-up using the Studio Adapter and CCU
Warranty
Labor: 1 year
Parts : 1 year
Scene File Feature
Self-illuminating Indicator
Buttons that are enabled are indicated in green, allowing you to identify the usable features easily. A button that is selected lights up in orange, allowing you to identify the current camera settings easily. In addition, the buttons and switches are also appropriately arranged according to their frequency of use.
Iris F-value Display
The iris F-value of the camera is indicated on the remote control. This enables you to perform accurate adjustment by grasping the iris condition at real-time.
- Joystick type control for iris and master black adjustments
- Control camera directly or via fiber or multicore system
- RM-HP790DE and Fiber System CCU connectable via cable with round 6pin connector
- 5 User scene files buttons
- F Stop LED display
- Rack mount controller
- Be also usable via direct connection to JVC ENG Camcorders
Technical Specifications
Manuals
Technical Specifications
Control Support for
- Camera Type:
- GY-HM890 series
- Camera Type:
- GY-HM850 series
- Camera Type:
- GY-HM790 series
- Camera Type:
- GY-HM750 series
- Camera Type:
- GY-HD250 series
- Camera Type:
- GY-HD200 series
- Camera Type:
- Telecast Fiber (Adapter necessary)
- Camera Type:
- Fourgerolle Camiflex Fiber units
- Max Control of X Cameras:
- 1 Unit (s)
Controlled Operations
- Shutter
- YES
- GAIN
- YES 18 db/ALC/LOLUX/Variable/LEVEL)
- Gamma
- YES
- IRIS
- YES (iris control unit / Iris F Value / Level)
- Detail
- YES
- Master Black
- YES
- Black settings (Stretch/Compress)
- YES (Normal/Stretch/Compress)
- KNEE
- YES Auto/ Knee Point
- White Balance
- YES (Manual/Presets/FAW/ AW A / AW B)
- AWB TRIGGER
- YES
- White Paint
- YES
- Black Paint
- YES
- CALL
- YES
- PREVIEW
- YES
- BARS
- YES
- Scene File
- YES 5
- Function Lock
- YES
IN-OUT´s Connections
- GPI
- for Tally over cable clamps (see instructions)
- RS232
- Over fix system Cable 5 Meter long
Power and Environment Information
- Power
- +9Volt over system cable 5 Meter
- Power consumption
- 2 Watts
- Operation Temperature in Celsius
- -5 degree to 40 degree
- Storage Temperature in Celsius
- -20 degree to 50 degree
Mechanical Informations
- Dimension
- W:105mm - H:310mm - D:141mm
- Weight
- 2.4 Kg
Include Package
- Cable
- FIX mounted system cable 5 Meter long
- Instruction Doc:
- YES
General Editing note
- Note :
- Simulated pictures.The values for weight and dimensions are approximate.E.&O.E. Design and specifications subject to change without notice.
