4KCAM COMPACT HANDHELD CAMCORDER w/INTEGRATED 12X LENS

GY-HM250U

1/2.3" 4K CMOS / 12x Zoom / 4K30p25p24p / 3G-SDI / HDMI / Easy setup Facebook Live and YouTube / Broadcast overlay


  • Media Class
  • OUT HDMI
  • File Format MOV
  • File Format AVCHD
  • IP Features FTP
  • Resolution 3840 x 2160

Warranty

Labor: 1 year

Parts : 1 year

Advanced IP Network Communication and Streaming

The GY-HM250 features JVC's latest IP communications engine giving you remote control and monitoring of vital camera and lens functions from a tablet, smartphone, or computer anywhere in the world. Live streaming is possible in HD or lower resolutions, depending on available bandwidth. JVC's Advanced Streaming Technology (AST) includes Zixi powered Forward Error Correction with ARQ, and SMPTE 2022 forward error correction delivering high quality streams even under challenging conditions. RTMP protocol makes it easier than ever to deliver your live streams to content delivery networks such as Facebook, YouTube and IBM Cloud. Just press one button and you're streaming to the world!*

*Requires appropriate network connection and adapter

Graphic & Titling Solutions for a Single Camera Operator

Designed for enhanced single-camera production, the GY-HM250U offers lower-third and full-screen titling solutions for recorded or streamed HD video output without an external CG or production switcher. Lower-third graphic overlays are generated and controlled using a browser-equipped device such as a tablet or smartphone. JVC's software utility lets customers upload logos or icons to be displayed in the lower-third of the recorded video. The camera also comes with several pre-installed color schemes and the ability to add your own text bar designs also exists. The new GY-HM250 is perfect for streaming broadcast news, weddings, school, family and church events, or literally any occasion you want to share live!

Integrated 12x Ultra HD Lens, 1/2.3-inch CMOS Sensor

Ultra high quality imagery begins with a precision 12x F1.2-3.5 optical zoom lens (35mm equivalent: 29.6-355mm). JVC's 4K CMOS sensor with 12.4M pixels delivers high sensitivity and excellent performance over a wide range of lighting conditions. Details are crisp and accurate throughout the entire image plane. When shooting in the HD mode, Dynamic Zoom combines optical zoom and pixel mapping to create seamless and lossless 24x zoom. This allows the camera to have a long zoom range while retaining its small form factor. Shooters will also appreciate the convenient ND filter wheel: 0, 1/4th and 1/16th positions.
















4K Ultra HD Recording at 150Mbps and Live Output

Working with 4K has never been easier! Insert an SDHC or SDXC (UHS-I Speed class3) memory card and record hours of 4K Ultra HD (3840 x 2160) material. Recordings are made using the Quicktime (.MOV) file format and are compatible with many popular editing systems. Connect a 4K Ultra HD monitor with a single HDMI cable, and view the camera's live 4K signal. You can also play back recorded files directly from the camera. The camera also downconverts UHD signals to standard HD for output through the built-in HDMI connector.
















4:2:2 Full HD recording at 50Mbps

The camera records 4:2:2 HD signals up to 60p at 50Mbps making it an ideal camera for general HD production work. 50Mbps files are stored in the Quicktime (.MOV) format for easy editing. Conventional AVCHD (4:2:0) recording is also possible, providing wide editing compatibility in an array of standard HD and SD formats.

Dual SDHC/SDXC Card Slots

Dual SDHC/SDXC card slots make this camera a truly versatile camcorder, offering such benefits as simultaneous recording and relay recording. In relay recording mode, you can shoot the event continuously over multiple cards—when one card is full, the camcorder switches automatically and seamlessly to the other card.



Clip Continuous Recording

In normal recording, when the recording stops, the image, audio, and accompanying data from the start until the end of the recording are recorded as one "clip" on the SD card. This mode allows you to consolidate several rounds of "startstop recording" into one clip.

For example, in normal recording three clips are generated as Recording 1, Recording 2, and Recording 3. However, recording in this mode the camera generates only one clip.

Web Friendly (Proxy) file formats

Lower resolution H.264 files (480x270p and 960x540p) may be recorded simultaneously with full HD files. These files are significantly smaller than HD files, and thus are very suitable for immediate posting to the web. A file recorded in the 960 x 540 mode is approximately 1/10th the size of a full HD file recorded at 35 Mbps, and therefore takes a fraction of the time to post. The smaller files may be quickly imported to an iPad for easy editing using iMovie or Pinnacle Studio. Transporting video to the web or back to the studio has never been faster.

S.L.I.M. Studio Camera System Design Concept

  • Simple design — addresses multiple levels of video operation and control.
  • Low Cost — a fraction versus traditional systems with full functionality.
  • IP Control — uses flexible and ubiquitous IP wired or wireless infrastructure
  • Multiple camera control — controls up to 100 cameras with a single RM-LP100U (tally control up to 5).


The SLIM system design is based on the RM-LP100U Remote Camera Control's latest firmware which enables painting and shading of our IP-capable camcorders, as well as simultaneously providing full control of our KY-PZ100 PTZ cameras! No other system offering incorporates a line-up of studio camcorder configurations providing the depth and diversity to meet the needs of professional applications from Education and House of Worship to Corporate, Industrial and Broadcast.

Click here for sample diagrams of wired and wireless systems.

Web API Command list

The following is link to command list document.

JVC Camcorder Web API Reference Version

  • Unique Facebook Live integration for easy, reliable streaming
  • Single 1/2.3-inch CMOS image sensor with 12.4 million pixels
  • High quality integrated 12x F1.2-3.5 zoom lens (35mm equivalent: 29.6-355mm)
  • Lower-third and full-screen titling solutions for recorded or streamed video
  • Zero Config configuration capability
  • Tele-macro mode provides better focus on close objects
  • Dynamic Zoom in HD mode maps pixels to create seamless and lossless 24x zoom
  • 4K Ultra HD recording (150 Mbps, 24/30p) to dual SDXC (UHS-I Speed class3) card
  • 4:2:2 recording at 4K/30p and 4K/24p
  • Full HD (24-60p) recording at 50Mbps
  • Live 4K UHD output via HDMI connector
  • 4K Ultra HD recording (70 Mbps, 24/30p) to SDXC/SDHC(Class 10) cards
  • Clip Continuous Recording mode
  • 120fps HD recording
  • Highlight display priority
  • 3G-SDI output for HD
  • HDMI output for UHD/HD
  • 2-channel XLR audio inputs with phantom power
  • Built-in stereo microphone
  • Advanced JVC streaming engine compatible with RTMP, Zixi and Wowza Streaming Engines
  • IP Network Remote Control, Remote Viewing,
  • Metadata editing, FTP clips
  • 3.5-inch color LCD display (920K pixel) and 0.24-inch color viewfinder (1.56M pixel) with smart focus assist function
  • Histogram Display
  • Includes handle unit and SSL-JVC50 7.4V battery
Technical Specifications
Manuals
Technical Specifications
Camera Front-End Specifications
Image Sensor (inch)
1/2.3 Inch CMOS
Number of Sensors
1
Mega Pixels
12.4
Gain in dB
0 to 36
Shutter speed
1/6 to 1/10000
White Balance modes
FAW, AWA, 3200K, 5600K, Manual
Color Matrix adjustment
Yes
Wide Dynamic Range Mode (WDR)
Yes
User selected function buttons
Yes, 13 (9 Buttons 4 Cross shaped)
User Customizes Menu
Yes
Optical Specifications
Lens mount
Internal
Optical Zoom in 4K x times
12
Digital Magnification x times
24
Lens F Number
1.2 to 3.5
Lens ratio from / to
4.67mm to 56.04mm
Lens ratio equivalent to 35mm
29.6mm to 355mm
Auto Focus
Yes
Special Auto Focus Features
Area Focus, Near/Far Modes, Face
Optical Image stabilization
Yes
Filter Diameter in mm
62mm
Built-in ND Filters
None, 1/4, 1/16
Recording Formats
Media
SDHC/SDXC
Media Class
4K/70 Mbps,HD and below Class 10
4K/150Mbps UHS1-U3 (no UHS-2)
Recording slots
2
Encoder
H.264
File Format MOV
Yes
File Format MP4
Yes
File Format AVCHD
Yes
Video Codec MPEG4 AVC/H264 4K/HD
Yes
Video Codec AVCHD
Yes
Recording specials
4:2:2 HD Record (H.264,50Mbps)
Simultaneous recording on 2 cards
Yes
Simultaneous recording in 2 modes
Yes
Resolution 3840 x 2160
Yes, 29,97p/25p/23.98p
Resolution 1920 x 1080
Yes, 60i/50i
Resolution 1440 x 1080
Yes, 60i/50i
Resolution 1280 x720
Yes, 60p/50/30p/25p
Resolution 720 x 576
Yes, 50i
Resolution 720 x 480
Yes, 60i
Resolution 640 x 360
Yes, 30p/25p
High Speed Recording
Yes
High Speed Recording Modes
1920x1080 QuickTime (MPEG-4, AVC/H.264)
120fps/100fps
Recording Data rate 1
150 Mbps (UHD)
Recording Data rate 2
70 Mbps (UHD)
Recording Data rate 3
8,17,24,28 Mbps (AVCHD)
Recording Data rate 4
35 Mbps (UHQ)
Recording Data rate 5
50 Mbps (XHQ/YUV422)
Recording Data rate 6
8 Mbps (SD)
Recording Data rate 7
9,8,5,3,1.2,0.8,0.3,0.2 (WEB)
SD Recording
Yes
Interval Recording
Yes
Pre Rec (retro) recording
Yes, 5 sec. (4K)
5,10,15 sec. (HD/SD)
Clip Trimming
Yes
Audio Channels
2
Audio Recording modes
LPCM 2ch, 48 kHz/16 bit (4k/HD/SD MOV), AC3 2ch (AVCHD), μ-law 2ch (Proxy)
IP Section of the Product
IP Main Connection
USB A Host
IP Connection supports
Ethernet, WIFI - and LTE USB Adapters
IP Features Live-Streaming
Yes
IP Features Remote
Yes, Via Web-Browser (no apps needed)
IP Features FTP
Yes, Different protocols
IP Features Meta-Data
Yes, Local and Remote editing and data exchange
Live-Streaming Bitrates
1920 x 1080 (59.94i/50i) Audio AAC 128 k 12/8/5/3 Mbps
1280 x 720 (59.94p/50p) Audio AAC 128 k 12/8/5/3 Mbps
1280 x 720 (29.97p/25p) Audio AAC 128 k 8/5/3/1.5 Mbps
720 x 480 (59.94i) 720 x 576 (50i) Audio AAC 128 k/64 k 8/5/3/1.5/0.8/0.3 Mbps
640 x 360 (29.97p/25p) Audio AAC 128 k/64k 3/1.5/0.8/0.3 Mbps
Live-Streaming Protocols
RTMP, MPEG2-TS/UDP, MPEG2-TS/RTP, RTSP/RTP, Zixi
Live-Streaming Single cast
Yes
Live-Streaming Multicast
Yes
Live-Streaming reconnect
Yes
Live-Streaming and simultaneous REC
Yes
Live-Streaming Pre-sets of destinations
4
FTP Protocol formats
FTP / SFTP / FTPS
FTP upload during REC
Yes
FTP servers presets
4
Meta-Data presets of servers
4
Special Features
Overlay for Broadcast-News
Yes
Self Modify Templates via SDP Generator
Yes, For News
Text support
Yes
Logo support
Yes
Watermark
Yes, Free Position
Full Screen Graphics
Yes, PNG or JPG Files Max 50 Images
LIVE Logo
Yes, Self design
Overlay output selection
Yes, REC
LIVE out
Stream
Input / Output Connections
OUT HDSDI
Yes, 3G HDSDI
OUT HDSDI Format max.
1080/60p,50p 8 Bit 4:2:2 EE
OUT HDMI
Yes
OUT HDMI Format max.
2160/30p,25p,24p 8 bit 4:2:2 EE
1080/60p,50p 8 bit 4:2:2 EE
OUT AV
Yes, 3.5mm mini jack
OUT Audio Line
Yes, 1 times 3.5mm mini jack
OUT Audio Headphone
Yes, 1 times 3.5mm mini jack
IN Audio XLR MIC/LINE
Yes, 2 times supports LINE and MIC Level with +48V
IN Audio AUX
Yes, 1 times 3.5mm mini jack
Build in Microphones
Yes, Stereo MIC
Wired remote IN
Yes, serial LANC 2.5mm mini jack
USB HOST
Yes
USB Data Exchange (Storage)
Yes
EVF and LCD
Operation Panel Type
LCD
Operation Panel Resolution
920K
Operation Panel Size diagonal in inches
3.5
Electronic Viewfinder (EVF) Type
LCOS
Electronic Viewfinder (EVF) Resolution
1,56M
Electronic Viewfinder (EVF) Size diagonal in inches
0.24
Power and Enviroment Spec´s
Power AC
Yes, DC12V (AC Adapter)
Power DC
Yes, 12V, Battery 7.4V
Power consumption
Approx 8.5W (with VF in 4K REC mode, default settings)
Operation Temperature in Celsius degrees
0 to 40
Storage Temperature in Celsius degrees
-20 to 50
Operation Humidity in %
30 to 80
Storage Humidity under %
85
Physical Information
Weight in lbs
3.53 lbs
Handle removable
Yes
Included Accessories
Battery
Yes, x1 (SSL-JVC50)
AC/DC adapter
Yes
Handle unit
Yes, with Professional Audio XLR support
Instructions
Yes
General Editing Note
NOTE:
Simulated pictures.The values for weight and dimensions are approximate.E.&O.E. Design and specifications subject to change without notice.
