ULTRA WIDE ANGLE 4K60P HEVC AUTO-TRACKING PTZ CAMERA with 3G-SDI/HDMI/USB/IP OUTPUT (BLACK)

KY-PZ510BU NEW

4K 60p50p / SRT / RTMPS / HEVC / H.265 / 80-degree FOV / Auto Tracking / USB UVC Cam

  • SRT Protocol
  • H.265 Codec
  • 4K Live Streaming

Warranty

Labor: 1 year

Parts : 1 year

New Advanced Auto Tracking

SMART (Subject Movement And Recognition Tracking)

Five Auto Tracking Settings

Standard, Area, Stage, Wide Area and Fine Adjustment

"Subject Movement and Recognition Tracking Auto Tracking" now has five new function settings to provide intelligent operation for sophisticated and engaging productions.


In the Standard mode, you can set the headroom spacing above the subject.

In the Area mode, The camera captures the Area frame where the target subject is visible. When the subject moves to an adjacent Area, the camera pans to the new Area.

Please take a look at the Five New SMART Auto Tracking Settings brochure.

Upgrade Your JVC PTZ Camera Firmware

Super-Wide 80-degree Field of View

Focal length is 3.47mm to 41.7mm (21.8 mm to 261.8mm, 35mm equivalent). Super-wide horizontal angle
of view is 80° which is ideal for use in offices, classrooms, studios, event facilities, sports venues and houses of worship.

Please take a look at the PTZ General brochure.

4K60p H.265/HEVC Streaming

    • Ultra-high resolution 4K60p streaming is ideal for viewing sports and events. Highly efficient H.265/HEVC compression technology also produces similar or better image quality than H.264 at 50% of the bitrate.

    Multi-Slice Encoding Technology

    Multi-slice encoding technology increases performance and efficiency while reducing latency to achieve optimal image quality of live transmissions in 4K60p HEVC mode.

    IP Address Display

    Rear Panel

    • YUV 4:2:2 12bit: HDMI output supports YUV 4:2:2 12bit and RGB 4:4:4 8bit. *Some switchers may not support the above signals.
    • 4K 60p50p streaming to YouTube: you can stream 4K(2160p60) from KY-PZ510/N to YouTube.
    • UVC (USB Video Class)
    • Multi-Camera synchronization with VITC and NTP
    • Save setup files: You can save the menu settings as a setup file on a PC.
    • Still image capture
    • H.264/H.265/Motion JPEG and dual streaming
    • 2-color tally useful for studio shooting
    • Internal Microphone
    Technical Specifications
    Manuals
    Technical Specifications
    Camera Front-End Specifications
    Image Sensor (inch)
    1/2,5 Inch CMOS
    Number of Sensors
    1
    Mega Pixels
    8.40
    Gain in dB
    0 to 45
    S/N in dB
    55
    Min. Illumination
    0.5Lux
    Shutter speed
    1/25 to 1/10000
    Optical Specifications
    Lens mount
    Internal
    Optical Zoom in 4K x times
    12
    Digital Magnification x times
    16
    Lens F Number
    1.8 to 3.7
    Lens ratio from / to
    3.4mm to 41.6mm
    Lens ratio equivalent to 35mm
    21.8mm to 261.8mm
    Auto Focus
    Yes
    PTZ Head Features
    PAN Angle in degree +/-
    162.5
    PAN Speed with AC Adapter max degree/sec.
    80.5
    PAN Speed with POE+ max degree/sec.
    80.5
    TILT Angle in degree
    -30 to 90
    TILT Speed with AC Adapter max degree/sec.
    49
    TILT Speed with POE+ max degree/sec.
    49
    Preset Positions
    255
    IP Section of the Product
    IP Main Connection
    Ethernet LAN RJ45 1000Base-T with POE+
    IP Connection supports
    Ethernet
    IP Features Live-Streaming
    Yes
    IP Features Remote
    Yes, via RM-LP100 or Web-Browser no apps needed
    Video Compression Codecs
    3
    H.265 Codec
    Yes
    H.264 Codec
    Yes
    MJPEG Codec
    Yes
    Live-Streaming Bitrates
    1~60 Mbit/s
    Live-Streaming Protocols
    SRT, RTMP, RTMPS, RTSP
    SRT Protocol
    Yes
    Live-Streaming Single cast
    Yes
    Live-Streaming Multicast
    Yes
    Live-Streaming Resolution
    3840x2160 (60p/50p/30p/25p), 1920x1080 (60p/50p/30p/25p/24p/i60/i50), 1280x720 (60p/50p/30p/25p/24p)
    4K Live Streaming
    Yes
    Live Streaming Audio Channels
    2
    Input / Output Connections
    OUT HDSDI
    Yes, 3G HDSDI
    OUT HDSDI Format max.
    1080/60p,50p
    OUT HDMI
    Yes
    OUT HDMI Format max.
    2160/60p, 50p
    OUT Audio Line
    Yes, 1 times 3.5mm mini jack
    IN Audio AUX
    Yes, 1 times 3.5mm mini jack
    Build in Microphones
    Yes
    PTZ Serial Interface RS-232C in/out
    Yes, over 8 PIN mini DIN
    PTZ Supported Protocols
    Serial, PelcoD, IP JVC, IP others
    Power and Enviroment Spec´s
    Power DC
    Yes, 12 Volt or 42V to 57V POE+ over Network LAN
    Power consumption
    12W
    Operation Temperature in Celsius degrees
    0 to 40
    Storage Temperature in Celsius degrees
    -40 to 60
    Included Accessories
    AC/DC adapter
    Yes
    Cable 1
    Yes, Power Cable
    Cable 2
    Yes, RS232 Cable
    Instructions
    Yes, User Manual, Warranty Card
    Remote Control unit
    Yes, IR controller
    Manuals
    INSTRUCTIONS(Installation/IP Address Settings)English20222.87MBViewDownload
    INSTRUCTIONSEnglish20222.41MBViewDownload
    INSTRUCTIONS(Installation/IP Address Settings)English20221.97MBViewDownload
    AUTO TRACKING (Standard, Area, other 3 modes.)English20241.84MBViewDownload
    INSTRUCTIONSFrench20222.41MBViewDownload
    INSTRUCTIONSGerman20222.35MBViewDownload
    INSTRUCTIONSItalian20222.34MBViewDownload
    INSTRUCTIONSRussian20222.42MBViewDownload
    INSTRUCTIONSSpanish20222.31MBViewDownload

    Accessories

    • KM-IP8

      Optimal for switching live programming in SD up to full HD 1080 60P, KM-IP8 provides a minimum of 8 NDI HX inputs at 1080 60p using vMix 4K licensed software. This product becomes a significant part of JVC's live IP production workflow solution.

    • KM-IP8S4

      Optimal for switching live programming in SD up to full HD 1080 60P with vMix 4K licensed software. KM-IP8S4 provides a minimum of 8 NDI HX inputs and 4-SDI inputs (up to 1080p60). This product becomes a significant part of JVC's live IP production workflow solution.

    • RM-LP100

      This advanced controller connects to your network and provides complete IP control of cameras in your facility or anywhere in the world through the internet.

    • RM-LP350G

      Desktop vMix control surface adds tactile controls and a traditional production switching interface to a vMix GO or any system running vMix software.

    • RM-LP450G

      The RM-LP450G can increase the speed of your live playback workflow. Slow-motion controller for the JVC vMix studio switchers. 　

    • RM-LP5G

      This compact joystick controller connects to your network and provides complete IP control of cameras in your facility or anywhere in the world through the Internet.

    • WMPZ500B

      This black rack mount kit was designed for wall mounting JVC PTZ cameras right side up or upside down.
