DLP Projector

LX-NZ3W Archived

$3,499.95

The LX-NZ3 is a high-performance 4K UHD/HDR home theater projector with laser light source technology BLU-Escent. Thanks to the BLU-Escent light source, it realizes brightness of 3,000 lumens so there is no need to pull the curtains every time. Plus, there is no need to care about the lamp life as it offers 20,000 hours of long life. Furthermore JVC's original Auto Tone Mapping function automatically adjusts to deliver the optimum HDR image all the time. This projector will enhance your viewing experience to a new level.

WARNING

COUNTERFEIT JVC PRODUCTS ARE BEING SOLD WITHIN THE UNITED STATES.

JVC Authorised Projector Dealers
  • 4K resolution (3840 x 2160) and HDR (HDR10/HLG) compatible.
  • Connectors: PC in, HDMI 1 with HDCP2.2 support, HDMI 2, USB Mini B, Trigger (12 V), USB Mini A (1.5 A power supply), and RS-232
  • "BLU-Escent" Laser Light Source
  • HDR (high dynamic range) for more realistic, dynamic images
  • Compact design for installation convenience: 41 cm by 34 cm, and less than 15 cm high (Approx. 16" by 13-1/2", and 5-3/4" in height)
  • "Auto Tone Mapping" for pristine HDR10 picture quality
  • 0.47-inch DMD for bright high-definition 4k images
  • Wide lens shift function: +/-60% vertical, +/-23% horizontal
  • 1.6x high-resolution lens
  • Compatible with HDMI standards (4K/60P 4:4:4) and HDCP 2.2
  • Available in 2 colors (black and white)
  • HDCP2.2 compatibility with HDMI 1 terminal to support video-streaming services and copyright-protected content including UHD BD discs
  • 4K input specs: Supports 4K60p/50p 4:4:4/8bit 4:2:2/12bit and 4K30p/25p/24p 4:4:4/12bit signals
  • 3,000 lm brightness and 20,000-hour long life
  • Dynamic contrast ratio: Infinity:1
Technical Specifications
Manuals
Technical Specifications
Device
0.47" DMD (1920 x 1080)
Resolution
3840 x 2160
Lens shift function
+/-60% vertical & +/-23% horizontal, motorized
Light source lamp
BLU-Escent (Laser Phosphor)
Lamp life
Approx. 20,000 hours in normal mode
Brightness
3,000 lm
Contrast Ratio
Infinity:1 (Dynamic contrast ratio)
Video input terminals (back panel)
PC x 1(D-sub 15pin)
Control terminals
RS232C x 1(D-sub 9-pin)
General
Noise level
29 dB (Eco) / 34 dB (Normal)
Power requirement
AC110 V-240 V, 50/60 Hz
Projector in use
360W
Standby
0.5W
Dimensions: W x H x D, mm
405 x 145.8 x 341
Dimensions: W x H x D, inches
15-7/8 x 5-3/4 x 13-1/2
Weight, kg
6.3
Weight, lbs
13.86
